TORQ HLX Black Edition Fullsize Tail Servo - Remote Control Helicopter, RC Helicopter, RC Airplane, Jet Aircraft Model Servo (HELIDIRECT)

Description

• - Using the newest Hall Sensor Technology; - Blistering 0.035 Second Transit Speed; - Dedicated Helicopter Rudder Servo;
• - Incredible Levels of Speed & Performance; - Ultra Precise, High Resolution Control; - Newly Design Steel Gear Train for Maximum Strength;
• - Excellent Thermal Dissipation via Finned 6061 Aluminum Case; - 8.4V High Voltage Ready; - Optimized for High Demand Rudder Control; - 6 Ball Bearings Construction;
• Motor Type: Brushless; Servo Arm Type: Futaba; Working Pulse Width / Frequency: 760us / 560Hz 450us-1050us;
• For helicopter rudder usage only. Please note that the TORQ HLX-T servo must be connected to a flybarless flight controller that is set at a 760us pulse width setting for proper functionality. Due to the 760us pulse width, if the servo is connected to a receiver or servo tester, the servo will not properly function due to these applications that use a 1520us pulse width.
• Servo Grommet is suggested use if you use our servo on Nitro Heli.

*** Features:
- Using the newest Hall Sensor Technology
- Blistering 0.035 Second Transit Speed
- Dedicated Helicopter Rudder Servo
- Incredible Levels of Speed & Performance
- Ultra Precise, High Resolution Control
- Newly Design Steel Gear Train for Maximum Strength
- Excellent Thermal Dissipation via Finned 6061 Aluminum Case
- 8.4V High Voltage Ready
- Optimized for High Demand Rudder Control
- 6 Ball Bearings Construction
*** Speed:
0.035 sec / 60 @ 7.4V
0.04 sec / 60 @ 6.0V
*** Torque:
11.0Kg.cm / 97.21 oz. in. @ 7.4V
9.0Kg.cm / 83.32 oz. in. @ 6.0V
*** Specifications:
Motor Type: Brushless
Servo Arm Type: Futaba
Working Pulse Width / Frequency: 760us / 560Hz 450us-1050us
Weight: 80g
Dimensions: 40mm x 20mm x 340mm (LxWxH)
Voltage Range: 6.0V - 8.4V
*** Usage Note:
For helicopter rudder usage only. Please note that the TORQ HLX-T servo must be connected to a flybarless flight controller that is set at a 760us pulse width setting for proper functionality. Due to the 760us pulse width, if the servo is connected to a receiver or servo tester, the servo will not properly function due to these applications that use a 1520us pulse width.
